Plant based protein is made by grinding dried Grains, legumes and seeds into a fine powder. The starch and fiber are removed, leaving a powdered concentrated protein substance (aka protein isolate). It is completely plant-based, unlike whey, casein, and egg-based protein powders, and therefore ideal for vegetarians and vegans.

We specialize and offer turnkey protein extraction solution.

Working principle

Material feed into the grinding chamber by a dosing feeder, they are impacted, sheared and grinded by high speed rotating unit and stator equipped with grinding tooth, the powdered material enters into the classifying area, under the action of centrifugal force from classifying wheel inside of impact mill and draught fan, the qualified powder is collected by the cyclone and bag filter, the oversized powder is continued to grinding.

Different fineness products can be achieved by adjusting the classifying wheel speed

Feature:

• Integration of mill and classifier, it is free from over grinding.

• Sharp particle size distribution, fineness D97=2-100μm is adjustable.

• Inner temperature is reduced by airflow, and grinding chamber is used water cooling jacket for cooling, suitable for heat-sensitive materials.

• Negative operation is free of dust pollution.

• Depolymerizing agglomerated material.

• Grinder equipped with slag discharge device, which can automatic discharge the hard and impurity materials.

• Compact structure.

• A little wearing parts and easy maintenance.
